Shanghai Dongmeng DLD Series Wheeled Mobile Jaw Crushing Plant is premium integrated primary crushin
This wheeled mobile jaw crushing unit integrates jaw crusher, vibrating feeder and multi-layer belt conveyors onto an independent wheeled trailer chassis. Different from stationary crushing lines, it requires no complicated foundation construction and can be rapidly relocated between construction sites by road transportation. Customizable full configurations are available to match customers’ diverse demands on raw material hardness, hourly output and finished aggregate sizes. The whole set adopts integrated modular design, with matched power system and stable transmission structure, delivering high continuous production efficiency while cutting overall operation and transfer costs.
| Model | DLDII2-69 | DLDII2-75 |
|---|---|---|
| Crusher Model | TZP69 | TZP7510 |
| Trailer Main Belt Conveyor | B800 | B1000 |
| Trailer Return Material Belt Conveyor | B650 | B800 |
| Trailer Finished Product Belt Conveyor | 2×B500 | 2×B500 |
| Transportation Length (mm) | 10070 | 11270 |
| Transportation Width (mm) | 2500 | 2800 |
| Transportation Height (mm) | 4500 | 4900 |
| Working Length (mm) | 10070 | 11270 |
| Working Width (mm) | 3400 | 4200 |
| Working Height (mm) | 4000 | 4500 |
| Total Installed Power (kW) | 75 | 140 |
| Trailer Axle | 2axle | 2axle |
| Overall Weight (T) | 41 | 51 |
Superior mobility and low relocation costs
Robust primary crushing performance and wide material adaptability
Customizable layouts for diverse working conditions
Integrated structure design, high production efficiency and low operating costs
