The DM-LIGHT tracked mobile jaw crushing station is a core product of Dongmeng, a brand with in-dept
DM-LIGHT Tracked Mobile Jaw Crushing Station is a core product developed by Dongmeng with in-depth dedication to the crushing and screening sector. It targets three major pain points at construction sites: difficult relocation, slow commissioning and high costs. Adopting a container-shippable design, this model greatly reduces transportation costs and time, adapts to multi-scenario operations, and brings new momentum to the industry.
DM-LIGHT Tracked Mobile Jaw Crushing Station is an innovative mobile crushing equipment launched by Dongmeng Heavy Industry to address on-site operation challenges. Centered on “mobility, modularization and intelligence”, it features a container-transportable design that breaks free from the limitations of traditional stationary equipment. It requires no complex infrastructure, enables quick start-stop and flexible relocation, and integrates an environmental dust suppression system. It realizes “moving the crushing plant to the job site”, balancing production efficiency and green environmental protection requirements.
Widely applied in mining, construction waste recycling, infrastructure construction and other fields, it adapts to harsh working conditions such as rugged mountain roads and narrow construction sites, meeting diverse demands for solid waste crushing and aggregate processing.
| DC75 Mobile Crushing Station Technical Parameters | |
| Main Unit Parameters | |
| Main Unit Model | DC75 |
| Main Motor Power | 75kw |
| Max Feed Size | 450mm |
| Processing Capacity | 55-150t/h |
| Main Unit Weight | 9500kg |
| Feeding & Discharging Parameters | |
| Feeding Height | 3050mm |
| Discharging Height | 2500mm |
| Hopper Volume | 3m³ |
| Power & Conveying Parameters | |
| Engine Power | 159kw |
| Main Belt Specification | B700×8M |
| Fines Belt Specification | B500×2.3M |
| Travel & Dimension Parameters | |
| Traveling Speed | 0.8-1.9km/h |
| Transport Dimension | 11.6×2.2×3.05m |
| Working Dimension | 11.6×2.2×3.05m |
| Total Equipment Weight | 23t |
No complex infrastructure required; it enables quick start-stop operation and flexible site relocation.
Integrated with environmental dust suppression design, it realizes "moving the crushing plant to the job site", balancing production efficiency and green environmental protection requirements.
Centered on mobility, modularization and intelligence, it adopts a container-shippable design to break free from the limitations of traditional stationary equipment.
